Chick take off

Technical specifications

Capacity (Estimated)	40,000 chicks/hour capacity	80,000 chicks/hour capacity
Number of Operators Maximum	4 persons take-off system	8 persons take-off system
Length chick coveryor	3.2 Meters	4.4 Meters
Width roller conveyor	600 mm
Width	1080 mm
Height	930 mm
Material	Stainless steel SS304 (where applicable)

Benefits

The platform is designed for manually separating good chicks from hatching debris, either can be used separately, or can be connected to the chick handling system.
This chick working table is ergonomically designed, with roller conveyor transporting hatcher baskets, efficient and comfortable for operators.
It is made of SS304 material where applicable, for optimum hygiene, easy to clean.
Can connect with hatcher basket roller belt, to send hatcher baskets to washing machine.

How It Works

Hatcher basket with chicks and hatching debris are placed onto the take-off roller belt manually.
Operators take out the good chicks and drop them into a chute under the rollers, then chicks will be transported by a belt to next process.
Hatcher baskets with egg shells, un-hatched eggs, and dead chicks are taken-away manually, or with conveyor transported to the waste processing and washing area.
