Hatcher RTU combined ventilation system

A system specially designed for hatchery, easy installation

Benefits

This system of air conditioning for hatchery, is an all in one unit of air conditioner and air handling unit. It cools or heats the outside air to a proper temperature and humidity, and supply to the incubators or hatchers.
This system is easy to install, no need complicated installation of water piping and pumps. After arrival at the hatchery, the main installation work is to connect some air ducts to the incubators, hatchers, or functional rooms.
The functions of this system includes: air filter, heating, cooling, humidification, dehumidification, pressure controlled air supply.
Different model of cooling capacities or ventilation capacities available, so that customer can choose according to their environment conditions.

Technical specifications

Model Cooling/Heating Capacity Ventilation Capacity
RTU20HP 59kW/16.8RT 1000-8000 m3/h
RTU25HP 71kW/20TR 1000-8000 m3/h
RTU30HP 87.2kW/25TR 1000-8000 m3/h
RTU40HP 112kW/32TR 1000-8000 m3/h
RTU50HP 140kW/40TR 1000-8000 m3/h
